1.1 product introduction

Application: used to measure the thermal shock resistance of refractory products.

Executive standard: the equipment is manufactured according to Yb / T 376.1 test method for thermal shock resistance of refractory products.

Instrument structure: it is composed of host, control cabinet and image acquisition system. The specimen collet can be rotated horizontally to facilitate sample loading, observation and recording of specimen end surface damage.

Control mode: IPC industrial computer is used for automatic control, with friendly interface and high temperature control precision (expert fuzzy control algorithm is applied), which can automatically record and analyze the damaged area of samples, and automatically record the thermal shock times of each sample. The original data can be converted into excel format, and the test report can be read and printed at any time. Image processing software has the functions of image storage, image printing and historical data query.

Safety performance: with broken coupling, broken rod, over-current, over-voltage alarm device, accident alarm and leakage protection function, complete safety facilities.

1.2 technical performance
